Grupos electrógenos vehiculares

Soluciones de energía personalizadas

Grupos electrógenos vehiculares

Modelo	Grupo electrógeno								Radiador (Externo)
	Primaria		Reserva		Motor	Nivel de ruido	Dimensiones	Peso	Dimensiones
	kVA	kW	kVA	kW	Velocidad	dB(A)/1m/3m//7m	(LWH )(mm)	kg	(LWH )(mm)
50Hz
YDE9V-H	8	8	9	9	1500rpm	70/65/55	1250×680×780	430	630×520×250
YDE11V-H	10	10	11	11	1500rpm	70/65/55	1250×680×780	430	680×570×270
YDE13V-H	12	12	13	13	1500rpm	70/65/55	1300×680×780	450	680×570×270
YDE16V-H	15	15	16	16	1500rpm	70/65/55	1350×680×780	490	720×620×290
YDE22V-H	20	20	22	22	1500rpm	70/65/55	1400×680×780	530	770×670×290
YDYM35V-H	25	25	28	28	1500rpm	70/65/55	1370×770×835	600	770×670×290
60Hz
YDE11V-H	10	10	11	11	1800rpm	70/65/55	1250×680×780	430	630×520×250
YDE13V-H	12	12	13	13	1800rpm	70/65/55	1250×680×780	430	680×570×270
YDE15V-H	14	14	15	15	1800rpm	70/65/55	1300×680×780	450	680×570×270
YDE19V-H	17	17	19	19	1800rpm	70/65/55	1350×680×780	490	720×620×290
YDE26V-H	24	24	26	26	1800rpm	70/65/55	1400×680×780	530	770×670×290
YDYM41V-H	30	30	33	33	1800rpm	70/65/55	1370×770×835	600	770×670×290

Modelo	Primaria		Reserva		Fases	Motor	Nivel de ruido	Dimensiones	Peso
Modelo	kVA	kW	kVA	kW	Fases	Velocidad	dB(A)/1m/3m//7m	(LWH )(mm)	kg
50Hz
YDKT11V	10	10	11	11	Monofásico	1500rpm	70/65/55	1550×650×900	550
YDKT13V3	12	10	13	11	Trifásico	1500rpm	70/65/55	1550×650×900	550
YDKT13V	12	12	13	13	Monofásico	3000rpm	74/69/59	1550×650×900	600
YDKT16V3	15	12	16	13	Trifásico	3000rpm	74/69/59	1550×650×900	600
YDKT17V	15	15	17	17	Monofásico	3000rpm	74/69/59	1550×750×1050	660
YDKT21V3	19	15	21	17	Trifásico	3000rpm	74/69/59	1550×750×1050	660
YDKT21V	24	19	21	21	Monofásico	1500rpm	70/65/55	1900×900×1150	780
YDKT26V3	15	19	26	21	Trifásico	1500rpm	70/65/55	1900×900×1150	780
YDKT28V	25	25	28	28	Monofásico	1500rpm	70/65/55	1900×900×1150	850
YDKT35V3	31	25	35	28	Trifásico	1500rpm	70/65/55	1900×900×1150	850
60Hz
YDKT12V	11	11	12	12	Monofásico	1800rpm	70/65/55	1550×650×900	550
YDKT15V3	13	11	15	12	Trifásico	1800rpm	70/65/55	1550×650×900	550
YDKT15V	14	14	15	15	Monofásico	1800rpm	70/65/55	1550×650×900	600
YDKT19V3	17	14	19	15	Trifásico	1800rpm	70/65/55	1550×650×900	600
YDKT20V	18	18	20	20	Monofásico	1800rpm	70/65/55	1550×750×1050	660
YDKT25V3	22	18	25	20	Trifásico	1800rpm	70/65/55	1550×750×1050	660
YDKT26V	24	24	26	26	Monofásico	1800rpm	70/65/55	1900×900×1150	780
YDKT28V3	24	24	28	22	Trifásico	1800rpm	70/65/55	1900×900×1150	780
YDKT31V	28	28	31	31	Monofásico	1800rpm	70/65/55	1900×900×1150	870
YDKT39V3	35	28	39	31	Trifásico	1800rpm	70/65/55	1900×900×1150	870

Modelo	Primaria		Reserva		Fases	Motor	Nivel de Ruido	Dimensiones	Peso
Modelo	kVA	kW	kVA	kW	Fases	Velocidad	dB(A)/1m/3m//7m	(LWH )(mm)	kg
50Hz
YDYM10V	9	9	10	10	Monofásico	1500rpm	70/65/55	1550×650×900	550
YDYM12V3	11	9	12	10	Trifásico	1500rpm	70/65/55	1550×650×900	550
YDYM12V	11	11	12	12	Monofásico	3000rpm	74/69/59	1550×650×900	600
YDYM15V3	14	11	15	12	Trifásico	3000rpm	74/69/59	1550×650×900	600
YDYM15V	14	14	15	15	Monofásico	3000rpm	74/69/59	1550×750×1050	660
YDYM20V3	18	14	20	15	Trifásico	3000rpm	74/69/59	1550×750×1050	660
YDYM25V	23	23	25	25	Monofásico	1500rpm	70/65/55	1900×900×1150	800
YDYM31V3	29	23	31	25	Trifásico	1500rpm	70/65/55	1900×900×1150	800
YDYM28V	28	28	31	31	Monofásico	1500rpm	70/65/55	1900×900×1150	900
YDYM39V3	35	28	39	31	Trifásico	1500rpm	70/65/55	1900×900×1150	900
60Hz
YDYM12V	11	11	12	12	Monofásico	1800rpm	70/65/55	1550×650×900	550
YDYM15V3	13	11	15	12	Trifásico	1800rpm	70/65/55	1550×650×900	550
YDYM14V	13	13	14	14	Monofásico	1800rpm	70/65/55	1550×650×900	600
YDYM18V3	16	13	18	14	Trifásico	1800rpm	70/65/55	1550×650×900	600
YDYM20V	18	18	20	20	Monofásico	1800rpm	70/65/55	1550×750×1050	660
YDYM25V3	22	18	25	20	Trifásico	1800rpm	70/65/55	1550×750×1050	660
YDYM26V	27	27	30	30	Monofásico	1800rpm	70/65/55	1900×900×1150	800
YDYM37V3	34	27	37	30	Trifásico	1800rpm	70/65/55	1900×900×1150	800
YDYM37V	34	34	37	37	Monofásico	1800rpm	70/65/55	1900×900×1150	900
YDYM46V3	42	34	46	37	Trifásico	1800rpm	70/65/55	1900×900×1150	900

Modelo	Primaria		Reserva		Fases	Motor	Nivel de Ruido	Dimensiones	Peso
Modelo	kVA	kW	kVA	kW	Fases	Velocidad	dB(A)/1m/3m//7m	(LWH )(mm)	kg
50Hz
YDSD9V	8	8	9	9	Monofásico	1500rpm	70/65/55	1400×750×950	540
YDSD11V3	10	8	11	9	Trifásico	1500rpm	70/65/55	1400×750×950	550
YDSD13V	12	12	13	13	Monofásico	3000rpm	74/69/59	1400×750×950	560
YDSD16V3	15	12	16	13	Trifásico	3000rpm	74/69/59	1400×750×950	570
YDSD18V	16	16	18	18	Monofásico	3000rpm	74/69/59	1400×750×950	580
YDSD22V3	19	16	22	18	Trifásico	3000rpm	74/69/59	1400×750×950	590
YDSD13V	12	12	13	13	Monofásico	1500rpm	70/65/55	1750×800×1050	650
YDSD16V3	15	12	16	13	Trifásico	1500rpm	70/65/55	1750×800×1050	660
YDSD18V	16	16	18	18	Monofásico	1500rpm	70/65/55	1750×800×1050	680
YDSD22V3	19	16	22	18	Trifásico	1500rpm	70/65/55	1750×800×1050	690
YDSD22V	20	20	22	22	Monofásico	1500rpm	70/65/55	1750×800×1050	700
YDSD28V3	24	20	28	22	Trifásico	1500rpm	70/65/55	1750×800×1050	720
YDSD28V	25	25	28	28	Monofásico	1500rpm	70/65/55	1900×800×1050	830
YDSD35V3	31	25	35	28	Trifásico	1500rpm	70/65/55	1900×800×1050	850
YDSD35V	32	32	35	35	Monofásico	1500rpm	70/65/55	1900×800×1050	880
YDSD44V3	40	32	44	35	Trifásico	1500rpm	70/65/55	1900×800×1050	900
60Hz
YDSD10V	9	9	10	10	Monofásico	1800rpm	70/65/55	1400×750×950	540
YDSD12V3	11	9	12	10	Trifásico	1800rpm	70/65/55	1400×750×950	550
YDSD13V	12	12	13	13	Monofásico	1800rpm	70/65/55	1500×750×950	600
YDSD16V3	15	12	16	13	Trifásico	1800rpm	70/65/55	1500×750×950	620
YDSD18V	16	16	18	18	Monofásico	1800rpm	70/65/55	1750×800×1050	680
YDSD22V3	19	16	22	18	Trifásico	1800rpm	70/65/55	1750×800×1050	690
YDSD22V	20	20	22	22	Monofásico	1800rpm	70/65/55	1750×800×1050	700
YDSD28V3	24	20	28	22	Trifásico	1800rpm	70/65/55	1750×800×1050	720
YDSD26V	24	24	26	26	Monofásico	1800rpm	70/65/55	1900×800×1050	830
YDSD32V3	30	24	32	26	Trifásico	1800rpm	70/65/55	1900×800×1050	850
YDSD35V	32	32	35	35	Monofásico	1800rpm	70/65/55	1900×800×1050	880
YDSD44V3	40	32	44	35	Trifásico	1800rpm	70/65/55	1900×800×1050	900
