Grupos electrógenos diésel industriales
Serie SDEC 12-2500KVA
SDEC es una subsidiaria del Grupo Automotriz de Shanghái, el mayor fabricante de automóviles en China. Además, mantiene una empresa conjunta con Mitsubishi para motores de servicio pesado. Los motores SDEC se destacan por su alta confiabilidad, rendimiento sólido y excelente adaptación a condiciones de alta altitud, lo que los hace aptos para minería, alquiler, telecomunicaciones, construcción, entre otros sectores.
Los grupos electrógenos Yorking con motor SDEC cubren un rango de potencia de 12 kVA a 2500 kVA. Estas unidades ofrecen una fuerte capacidad de carga instantánea, excelente rendimiento de arranque a baja temperatura, y pueden operar tanto en 50 Hz como en 60 Hz, lo que garantiza una gran flexibilidad.
| Modelo | Primaria | Reserva | Motor | Alternador | Dimensiones(LxWxH)(MM) | ||||
| kVA | kW | kVA | kW | Modelo | Regulador | Modelo | Silencioso | ||
| Monofásico | |||||||||
| YDSD13E/S-E/S/SS | 12 | 12 | 13 | 13 | 4Z2.3-G11 | M | Y164D/1P | 1800*800*1150 |  YDSD13E&S-E&S&&SS Technical Data.pdf |
| YDSD18E/S-E/S/SS | 16 | 16 | 18 | 18 | 4Z2.7-G11 | M | Y184ED/1P | 1920*850*1150 | YDSD18E&S-E&S&&SS Technical Data.pdf |
| YDSD22E/S-E/S/SS | 20 | 20 | 22 | 22 | 4Z3.0-G11 | M | Y184EF/1P | 2058*880*1150 | YDSD22E&S-E&S&&SS Technical Data.pdf |
| YDSD28E/S-E/S/SS | 25 | 25 | 28 | 28 | 4Z3.2-G11 | M | Y184G/1P | 2218*880*1150 | YDSD28E&S-E&S&&SS Technical Data.pdf |
| Trifásico | |||||||||
| YDSD17E3/S3-E/S3/SS3 | 15 | 12 | 16 | 13 | 4Z2.3-G11 | M | Y164D | 1800*800*1150 | YDSD17E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD23E3/S3-E/S3/SS3 | 20 | 16 | 23 | 18 | 4Z2.7-G11 | M | Y184ED | 1920*850*1150 | YDSD23E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD28E3/S3-E/S3/SS3 | 25 | 20 | 28 | 22 | 4Z3.0-G11 | M | Y184EF | 2058*880*1150 | YDSD28E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD34E3/S3-E/S3/SS3 | 31 | 25 | 34 | 28 | 4Z3.2-G11 | M | Y184G | 2218*880*1150 | YDSD34E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD44E3/S3-E/S3/SS3 | 40 | 32 | 44 | 35 | 4ZT3.2-G11 | M | Y184J | 2218*880*1150 | YDSD44E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD55E3/S3-E/S3/SS3 | 50 | 40 | 55 | 44 | 4ZT3.5-G21 | E | Y224D | 2520*1000*1250 | YDSD55E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD70E3/S3-E/S3/SS3 | 63 | 50 | 69 | 55 | 4ZT4.1-G21 | E | Y224E | 2520*1000*1250 | YDSD70E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD75E3/S3-E/S3/SS3 | 68 | 55 | 75 | 60 | 4ZTAA4.1-G21 | E | Y224F | 2520*1000*1250 | YDSD75E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD88E3/S3-E/S3/SS3 | 75 | 60 | 83 | 66 | 4ZTAA4.1-G22 | E | Y224G | 2520*1000*1250 | YDSD88E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD110E3/S3 | 100 | 80 | 110 | 88 | SC4H140D2 | E | Y274C | 2660*1100*1520 | YDSD110E3&S3. Technical Data.pdf |
| YDSD125E3/S3 | 113 | 90 | 125 | 100 | SC4H160D2 | E | Y274D | 2660*1100*1520 | YDSD125E3&S3. Technical Data.pdf |
| YDSD138E3/S3 | 125 | 100 | 138 | 110 | SC4H180D2 | E | Y274DS | 2660*1100*1520 | YDSD138E3&S3. Technical Data.pdf |
| YDSD150E3/S3 | 137 | 110 | 150 | 120 | 6HTAA6.5-G21 | E | Y274E | 3150*1100*1750 | YDSD150E3&S3. Technical Data.pdf |
| YDSD165E3/S3 | 150 | 120 | 165 | 132 | SC7H205D2 | E | Y274FS | 3150*1100*1750 | YDSD165E3&S3. Technical Data.pdf |
| YDSD175E3/S3 | 163 | 130 | 175 | 140 | SC7H220D2 | E | Y274G | 3250*1100*1750 | YDSD175E3&S3. Technical Data.pdf |
| YDSD206E3/S3 | 188 | 150 | 206 | 165 | SC7H250D2 | E | Y274G | 3250*1100*1750 | YDSD206E3&S3. Technical Data.pdf |
| YDSD220E3/S3 | 200 | 160 | 220 | 180 | SC8D280D2 | E | Y274H | 3650*1280*1950 | YDSD220E3&S3. Technical Data.pdf |
| YDSD250E3/S3 | 225 | 180 | 250 | 200 | SC9D310D2 | E | Y274J | 3650*1280*1950 | YDSD250E3&S3. Technical Data.pdf |
| YDSD275E3/S3 | 250 | 200 | 275 | 220 | SC9D340D2 | E | Y274K | 3650*1280*1950 | YDSD275E3&S3. Technical Data.pdf |
| YDSD313E3/S3 | 275 | 220 | 313 | 250 | SC10E380D2 | E | Y4D | 4110*1500*2200 | YDSD313E3&S3. Technical Data.pdf |
| YDSD350E3/S3 | 313 | 250 | 350 | 280 | SC10E420D2 | E | Y4ES | 4210*1500*2200 | YDSD350E3&S3. Technical Data.pdf |
| YDSD375E3/S3 | 344 | 275 | 375 | 300 | SC10E460D2 | E | Y4FS | 4210*1500*2200 | YDSD375E3&S3. Technical Data.pdf |
| YDSD400E3/S3 | 362 | 290 | 400 | 320 | SC10E480D2 | E | Y4F | 4310*1700*2200 | YDSD400E3&S3. Technical Data.pdf |
| YDSD413E3/S3 | 375 | 300 | 413 | 330 | SC13E500D2 | E | Y4F | 4310*1700*2200 | YDSD413E3&S3. Technical Data.pdf |
| YDSD440E3/S3 | 400 | 320 | 437 | 350 | SC13E550D2 | E | Y4FG | 4310*1700*2200 | YDSD440E3&S3. Technical Data.pdf |
| YDSD500E3/S3 | 450 | 360 | 500 | 400 | 6ETAA12.8-G31 | CR | Y5C | 4310*1700*2200 | YDSD500E3&S3. Technical Data.pdf |
| YDSD550E3/S3 | 500 | 400 | 550 | 440 | 6ETAA12.8-G310 | CR | Y5D | 4310*1700*2200 | YDSD550E3&S3. Technical Data.pdf |
| YDSD625E3/S3 | 563 | 450 | 625 | 500 | SC25K778D2 | E | Y5ES | 5550*1950*2500 | YDSD625E3&S3. Technical Data.pdf |
| YDSD688E3/S3 | 625 | 500 | 688 | 550 | SC25K855D2 | E | Y5FS | 5550*1950*2500 | YDSD688E3&S3. Technical Data.pdf |
| YDSD750E3/S3 | 700 | 560 | 750 | 600 | SC25K930D2 | E | Y6B | 5700*2050*2540 | YDSD750E3&S3. Technical Data.pdf |
| YDSD825E3/S3 | 750 | 600 | 825 | 660 | SC25K990D2 | E | Y6B | 5700*2050*2540 | YDSD825E3&S3. Technical Data.pdf |
| YDSD900E3/S3 | 825 | 660 | 900 | 720 | 6KTAA25-G31 | CR | Y6B | 5700*2050*2540 | |
| YDSD1000E3/S3 | 900 | 720 | 1000 | 800 | 6KTAA25-G320 | CR | Y6D | 5900*2250*2550 | YDSD1000E3&S3. Technical Data.pdf |
| YDSD1100E3/S3 | 1000 | 800 | 1100 | 880 | 6KTAA25-G321 | CR | Y6E | 5900*2250*2550 | YDSD1100E3&S3. Technical Data.pdf |
| YDSD1688E3/S3 | 1563 | 1250 | 1687.5 | 1350 | 12KTA58-G35 | CR | LSA50.2 VL10 | ISO 40'ft HQ | YDSD1688E3&S3. Technical Data.pdf |
| YDSD1875E3/S3 | 1688 | 1350 | 1875 | 1500 | 12KTA58-G34 | CR | LSA52.3 S5 | ISO 40'ft HQ | YDSD1875E3&S3. Technical Data.pdf |
| YDSD2063E3/S3 | 1875 | 1500 | 2062.5 | 1650 | 12KTA58-G33 | CR | LSA52.3 S6 | ISO 40'ft HQ | YDSD2063E3&S3. Technical Data.pdf |
| YDSD2250E3/S3 | 2000 | 1600 | 2250 | 1800 | 12KTA58-G32 | CR | LSA52.3 S6 | ISO 40'ft HQ | YDSD2250E3&S3. Technical Data.pdf |
| YDSD2500E3/S3 | 2250 | 1800 | 2500 | 2000 | 12KTA58-G31 | CR | LSA52.3 L9 | ISO 40'ft HQ | YDSD2500E3&S3. Technical Data.pdf |
| Modelo | Primaria | Reserva | Motor | Alternador | Dimensiones(LxWxH)(MM) | ||||
| kVA | kW | kVA | kW | Modelo | Regulador | Modelo | Silencioso | ||
| Monofásico | |||||||||
| YDSD19E/S/SS | 16 | 16 | 18 | 18 | 4Z2.3-G12 | M | Y164D/1P | 1800*800*1150 | YDSD19E&S&SS Technical Data.pdf |
| YDSD23E/S/SS | 20 | 20 | 22 | 22 | 4Z2.7-G12 | M | Y184E/1P | 1920*850*1150 | YDSD23E&S&SS Technical Data.pdf |
| YDSD26E/S/SS | 24 | 24 | 26 | 26 | 4Z3.0-G12 | M | Y184EF/1P | 2058*880*1150 | YDSD26E&S&SS Technical Data.pdf |
| Trifásico | |||||||||
| YDSD24E3/S3/SS3 | 20 | 16 | 23 | 18 | 4Z2.3-G12 | M | Y164D | 1800*800*1150 | YDSD24E3&S3&SS3 Technical Data.pdf |
| YDSD29E3/S3/SS3 | 25 | 20 | 28 | 22 | 4Z2.7-G12 | M | Y184ED | 1920*850*1150 | YDSD29E3&S3&SS3 Technical Data.pdf |
| YDSD33E3/S3/SS3 | 30 | 24 | 33 | 26 | 4Z3.0-G12 | M | Y184EF | 2058*880*1150 | YDSD33E3&S3&SS3 Technical Data.pdf |
| YDSD45E3/S3/SS3 | 40 | 32 | 44 | 35 | 4Z3.2-G12 | M | Y184H | 2218*880*1150 | YDSD45E3&S3&SS3 Technical Data.pdf |
| YDSD48E3/S3/SS3 | 44 | 35 | 48 | 39 | 4ZT3.2-G12 | M | Y184H | 2218*880*1150 | YDSD48E3&S3&SS3 Technical Data.pdf |
| YDSD70E3/S3/SS3 | 63 | 50 | 70 | 56 | 4ZT3.5-G21 | E | Y224D | 2520*1000*1250 | YDSD70E3&S3&SS3 Technical Data.pdf |
| YDSD83E3/S3/SS3 | 75 | 60 | 83 | 66 | 4ZT4.1-G21 | E | Y224E | 2520*1000*1250 | YDSD83E3&S3&SS3 Technical Data.pdf |
| YDSD88E3/S3/SS3 | 80 | 64 | 88 | 70 | 4ZTAA4.1-G21 | E | Y224F | 2520*1000*1250 | YDSD88E3&S3&SS3 Technical Data.pdf |
| YDSD100E3/S3/SS3 | 90 | 72 | 100 | 80 | 4ZTAA4.1-G22 | E | Y224F | 2520*1000*1250 | YDSD100E3&S3&SS3 Technical Data.pdf |
| YDSD126E3/S3 | 113 | 90 | 125 | 100 | 4HTAA4.3-G21 | E | Y274CS | 2660*1100*1520 | YDSD126E3&S3 Technical Data.pdf |
| YDSD140E3/S3 | 125 | 100 | 140 | 112 | 4HTAA4.3-G23 | E | Y274D | 2660*1100*1520 | YDSD140E3&S3 Technical Data.pdf |
| YDSD165E3/S3 | 150 | 120 | 165 | 132 | 6HTAA6.5-G21 | E | Y274DS | 3150*1100*1750 | YDSD165E3&S3 Technical Data.pdf |
| YDSD180E3/S3 | 160 | 128 | 175 | 140 | 6HTAA6.5-G22 | E | Y274E | 3250*1100*1750 | YDSD180E3&S3 Technical Data.pdf |
| YDSD220E3/S3 | 200 | 160 | 220 | 176 | 6HTAA6.5-G23 | E | Y274G | 3250*1100*1750 | YDSD220E3&S3 Technical Data.pdf |
| YDSD250E3/S3 | 225 | 180 | 250 | 200 | 6DTAA8.9-G21 | E | Y274G | 3650*1220*1950 | YDSD250E3&S3 Technical Data.pdf |
| YDSD275E3/S3 | 250 | 200 | 275 | 220 | 6DTAA8.9-G24 | E | Y274J | 3650*1220*1950 | YDSD275E3&S3 Technical Data.pdf |
| YDSD313E3/S3 | 275 | 220 | 313 | 250 | 6DTAA8.9-G23 | E | Y274J | 3650*1280*1950 | YDSD313E3&S3 Technical Data.pdf |
| YDSD375E3/S3 | 350 | 280 | 375 | 300 | 6ETAA11.8-G22 | E | Y4D | 4210*1500*2200 | YDSD375E3&S3 Technical Data.pdf |
| YDSD437E3/S3 | 400 | 320 | 437 | 350 | 6ETAA12.8-G22 | E | Y4FS | 4310*1700*2200 | YDSD437E3&S3 Technical Data.pdf |
| YDSD500E3/S3 | 450 | 360 | 500 | 400 | 6ETAA12.8-G32 | CR | Y4F | 4310*1700*2200 | YDSD500E3&S3 Technical Data.pdf |
| YDSD550E3/S3 | 500 | 400 | 550 | 440 | 6ETAA12.8-G310.1 | CR | Y5C | 4310*1700*2200 | YDSD550E3&S3 Technical Data.pdf |
| YDSD619E3/S3 | 563 | 450 | 619 | 495 | 6KTAA25-G311 | EUP | Y5D | 5550*1950*2500 | YDSD619E3&S3 Technical Data.pdf |
| YDSD688E3/S3 | 625 | 500 | 688 | 550 | 6KTAA25-G310 | EUP | Y5ES | 5550*1950*2500 | YDSD688E3&S3 Technical Data.pdf |
| YDSD770E3/S3 | 700 | 560 | 770 | 616 | 6KTAA25-G39 | EUP | Y5E | 5700*2050*2540 | YDSD770E3&S3 Technical Data.pdf |
| YDSD825E3/S3 | 750 | 600 | 825 | 660 | 6KTAA25-G32.1 | CR | Y5FS | 5700*2050*2540 | YDSD825E3&S3 Technical Data.pdf |
| YDSD908E3/S3 | 825 | 660 | 908 | 726 | 6KTAA25-G31.1 | CR | Y6B | 5700*2050*2540 | YDSD908E3&S3 Technical Data.pdf |
| YDSD990E3/S3 | 900 | 720 | 990 | 792 | 6KTAA25-G320.1 | CR | Y6C | 5900*2250*2550 | YDSD990E3&S3 Technical Data.pdf |
| YDSD1100E3/S3 | 1000 | 800 | 1100 | 880 | 6KTAA25-G321.1 | CR | Y6D | 5900*2250*2550 | YDSD1100E3&S3 Technical Data.pdf |
